CODE: CR1524-46E

Juvo Hybrid Shower Commode With Sliding Footplate - 460mm

  • Assists transportation of the patient for showering and toileting
  • Can be positioned over the toilet
  • Durable total stainless steel frame
  • Selection of seamless PU padded seats & Pressure care seats (open or closed fronts)
  • Removable seat
  • Reinforced seat/back frame
  • Easy foot operated sliding, non-slip,weight bearing footrest platform
  • Now with braking stainless steel 125mm castors
  • Swing back independent armrests to assist in side transfer and patient access
  • Two position height adjustable armrests
  • Safety arms provide user security & safety
  • Stainless steel pan rack guides
  • Max User Weight 200kg
  • This product is tested and certified to Australian Standards


  • Assists transportation of patient for showering and toileting
  • Clear rear open space enabling positioning over the toilet
  • Easy access for hygiene with open armrest design
  • Deeper access front trough design for easy cleaning
  • Integral pan carrier glides. Back saver design, assists with emptying the bowl, can be removed half way, self supporting while the bowl/pan is removed

Design & Modifications

  • Grade 304 stainless steel heavy wall thickness tubing forming robust frame, durable design to withstand extensive wet area use
  • Open armrest design meaning smaller commode can be used in tight spaces while allowing for natural hip and thigh prominence. Eliminating "pinch point" between armrest and seat
  • Reinforced seat/back frame and armrests - weight bearing.
  • Comfort grip sliding footrest
  • Stylish sturdy base to give confidence to client and carer

Positioning & Comfort

  • Stainless steel 125mm total locking castors for effortless manoeuvring, Juvo Registered Design
  • Easy removable seat, using Juvo Registered Design "Klipps" System
  • Selection of seamless Polyurethane padded seats & pressure care seats (open or closed fronts)
  • Swing-back independent armrests to assist in side transfer and patient access - two position height adjustment
  • Locking safety arms provide user security and safety
  • Flexible impervious non-woven back straps conforming to client shape for support and comfort. Antibacterial and non-suction designed straps to avoid skin tear when client is wet
Seat Width (mm)460
Width between arms (mm)490
Seat depth (mm)435
Seat height Anterior (mm)595
Seat height Posterior (mm)565
Seat to Heel (mm)400
Width Overall (mm)540
Height Overall (mm)1020
Depth Overall (mm)800
Armrest height from seat High (mm)240
Armrest height from seat Low (mm)200
Backrest height to top strap (mm)340
Aperture, wall to rear (mm)225
Toilet bowl clearance max width x height (mm)410x500
Toilet bowl clearance underside pan glides
max width x height (mm)
Max user weight (kg)200
Chair weight excluding seat, (kg)12.8
